HemataStat II Hematocrit Analyzer


Hematastat-Hematocrit-Analyzer-2

Key features

  • 60 second spin time
  • Built-in reader
  • Whisper-quiet operation
  • Optional rechargeable battery
  • Dimensions: 127 x 177 x 279mm
  • Lightweight: 2 lbs / 907 g

Inquire now

Quickly measures hematocrit in any setting


EKF Diagnostics’ HemataStat II is  a microhematocrit centrifuge that provides a quantitative hematocrit reading for up to six blood samples from one 60 second spin.

Hematocrit is the volume percentage (%) of red blood cells in blood. The measurement is taken as the amount of red blood cells in relation to the amount of plasma from a spun capillary or venous sample.

HemataStat II is ideal for point-of care and laboratory use in clinics and hospitals. Its compact size and the optional battery pack makes it well suited for outreach programs and also for veterinary settings. HemataStat II is used in 100% of the plasma collection centers in the USA as it allows a simple hematocrit measurement and further-on analysis of the plasma fraction for proteins. The multi-lingual display provides easy to follow instructions to ensure accurate results every time.

HemataStat II combines easy maintenance with a high degree of user safety, for example, heparinized ClearCrit® tubes are used to collect the blood sample and are available in plastic,  Mylar®  wrapped glass or self-sealing Mylar® wrapped glass . Two different diameters of tube are available for low and regular sample volumes.

 The high quality HemataSEAL® tube sealant seals both plastic and glass tubes equally well to  eliminate leakages and blow-outs and ensure accurate and reliable results time after time.

HemataStat II combines easy maintenance with a high degree of user safety, for example, heparinized ClearCrit tubes are used to collect the blood sample and are available in plastic, glass or Mylar® coated glass, designed for maximum user safety. Two different diameters of tube are available for low and regular sample volumes.

Additional safety features includes the high quality HemataSEAL tube sealant. HemataSEAL eliminates leakages and blow-outs and ensures accurate and reliable results time after time.

Quantitative hematocrit readings for up to six blood samples from a single 60 second spin.

Easy measurements in 3 steps


HemataStat-Hematocrit-Analyzer-1-step
1.  Collect capillary blood sample.
HemataStat-Hematocrit-Analyzer-2-step
2.  Place the sealed tube into the centrifuge and spin for 60 sec.
HemataStat-Hematocrit-Analyzer-3-step
3.  Results are displayed on screen.

HemataStat II hematocrit analyzer specifications


Easy to use

  • CLIA waived
  • Step by step instructions on display
  • Multi-lingual menu
  • Clear, disposable tube holders for safe and easy maintenance
  • Optional rechargeable battery pack for field use

Innovative technology

  • Whisper quiet operation
  • Six place rotor
  • Built-in tachometer with low RPM alert
  • 1,548 - 2,312 RCF
  • Compact: 127 (h) x 177 (w) x 279 (d) mm /  5”(h) x 7”(w) x 11”(d)
  • Lightweight: 907 g / 2 lbs

Fast & accurate

  • 60 second spin time
  • Built-in low RPM alert
  • Accuracy +/- 0.5%
  • Correlation coefficient is 0.9978 compared to the NCCLS reference method

Three simple steps

  1. Fill up to six tubes half to three quarters full
  2. Seal the sample tube, place it into the centrifuge and spin for 60 seconds
  3. Read tubes on built-in reader tray. Results  are displayed on screen
HemataStat-Hematocrit-Analyzer-detail-1
Six place rotor
HemataStat-Hematocrit-Analyzer-detail-2
Step by step instructions on screen



Frequently asked questions

Watch the video


HemataStat Video


Downloads

ctaHemoV2

HemataStat II​ is CLIA waived and also has a CE mark for sale in the European Market.

United States Blood Banks Contact:

Call 830-249-0772

Email sales2@ekfdiagnostics.com
